Main performance and features
- Excellent stability and high precision: Utilizing internationally renowned brand motors and high-quality components, the machine boasts a stable structure, smooth operation, and precise control over material extrusion speed, temperature, and other parameters, resulting in high-quality products.
- User formula storage and retrieval: Multiple formulas can be stored for convenient production and debugging.
- High safety: Emergency stop devices and various safety protections ensure operator safety.
- Easy operation: The equipment is simple and easy to understand; users can quickly learn to operate it by simply following the on-screen instructions.
- Personalized customization: Customization is available to meet different material and process requirements, satisfying individual user needs.
Application of Pipe Extrusion Line
- New product development and formula optimization
- Teaching experiments in universities and research institutions
- Small-batch production and customized manufacturing
- Quality inspection and control
Technical parameters of Pipe Extrusion Line
| Item | parameters |
| Applicable materials | PLA、ABS、PA 、PEBAX |
| screw diameter | 19mm |
| Screw length-to-diameter ratio | 25:1 |
| Power | 1.5kw |
| Product Specifications | 0.2-2mm |
| capacity | 0.1~2kg/h |
| Maximum operating temperature | 350C |
| Voltage | 220V，50Hz |
| Total Power | about 4.5kW |
| Control method | PLC |
| Dimensions | 1960mm*514mm*1252mm |
